Hotel IP phones are an integral part of modern hospitality infrastructure, providing enhanced communication services for guests and operational efficiencies for hotel staff. By leveraging the power of IP networks, hotels can offer better service, improve guest satisfaction, and streamline their operations.
Physical Specifications
● Adapter input: AC100-240V
● Adapter output: DC 5V/1A
● WAN Port -10/100 BASE-T RJ-45 for LAN
● LAN Port-10/100 BASE-T RJ-45 for PC
● Handset: RJ9
● Power consumption: IDLE: 2.5W active: 2.8W
● Operation temperature: 0〜40℃
● Relative humidity: 10〜65％
● Main chipset: Broadcom
● SDRAM: 16MB
● FLASH: 8MB
● Dimension: 213x170x130 mm
Audio Specifications
● HD voice: HD handset
● Codec: G.711A/U, G.723.1 high/low, G.729AB, G.722, G.726-32
● DTMF: in-band, RFC2833, and SIP INFO
● Full-duplex acoustic echo canceller (AEC) – hands-free mode, 96ms tail-length
● Voice activity detection (VAD) / comfort noise generation (CNG) / background noise estimation (BNE) / noise Reduction (NR)
● Packet loss concealment (PLC)
● Dynamic adaptive jitter buffer up to 300ms
● DTMF: In-band, out-of-band – DTMF-relay(RFC2833) / SIP INFO
Phone Features
● vxworks OS
● Support SIP2.0 (RFC3261) and correlative RFCs
● SIP supports 1 SIP server and backup SIP proxy servers
● Supports SIP UDP / TCP/ TLS
● SIP supports SIP domain, SIP authentication (none, basic, MD5), DNS name of the server, Peer to Peer / IP Call
Key Features
● 6 soft keys programmable
● Multi languages displayed(web)
Key Hotel IP Phone Applications
▷ Guest Service Applications
▷ Communication Applications(VoIP Calls, Voicemail, Text Messaging)
▷ Hotel Information Applications
▷ Entertainment Applications
▷ Personalization Applications
▷ Integration with PMS
▷ Security and Privacy Applications
